Electrical Steel Transformer Core

Core Manufacturing Excellence – From Coil to Core
The process from grain‑oriented silicon steel coil to core involves:
1. Slitting – Precision width cutting with controlled burr height.
2. Punching / Cutting – Step‑lap, mitered, or straight cuts with minimal magnetic degradation.
3. Stacking – Automated or manual, ensuring uniform stacking factor .
4. Annealing (if required) – Stress‑relief annealing restores magnetic properties after cutting; coating must survive this process.
5. Assembly & Clamping – Uniform pressure prevents lamination vibration and maintains low core loss.

Quantity:
Availability:





Inquire Add to Basket

Product Description

By core Construction-Magnetic Path& Manufacturing, to Identify cores of transformer

1774423446584

1733207892913868

Core‑Type Transformers

Windings surround the limbs. Stepped lap joints reduce joint losses; cores are assembled from laminations or wound strip. High‑permeability GO minimizes core cross‑section and copper losses.

Shell‑Type Transformers

Core surrounds the windings. Flux‑dividing structure with stacked laminations; precise stacking ensures magnetic symmetry. GO with excellent flatness and uniform coating for consistent stacking factor.

Wound Cores (C‑cores, toroidal)

Continuous strip wound into a ring, cut or uncut. Used in single‑phase distribution, instrument, and specialty transformers. GO requires high ductility, uniform tension, and narrow strip widths for toroids.
